UL 1015 c-UL Type TEW
Category : Cables
Product Description
UL 1015 is a PVC insulated wire designed for internal wiring in electrical and electronic equipment. It offers heat resistance up to 105°C, a voltage rating of 600V, and good flexibility for easy installation
Product Name
UL 1015 c-UL Type TEW
Type
UL 1015
Category Type
Electronic Cable
Range Size (AWG/mm²)
10 ~ 28 AWG
Material
Conductor: Stranded or solid tin-coated annealed copper wires
Insulation: PVC (Polyvinyl Chloride)
Sheath: -
Temperature
Heat-resistance class 105℃
Standar Packing
Coil
Application
Internal Wiring of appliances and Electronic Equipment’s (Lead wire of primary circuits).
Product Standard
JIS C3152 (Tin Coated Annealed Copper Wire)
JIS C3102 (Annealed Copper Wire)
UL 758 (Appliance Wiring Material)
UL 2556 (Wire and Cable Test Methods)
RoHS Compliance
Yes
Rating Voltage
600 VAC or 750 VDC
Heat Resistance Class
80℃, 90℃ or 105℃
Test
Product Description
UL 1015 is a PVC insulated wire designed for internal wiring in electrical and electronic equipment. It offers heat resistance up to 105°C, a voltage rating of 600V, and good flexibility for easy installation
