UL 1007 c-UL Type TR-64
Category : Cables
Product Description
UL1007 is a PVC insulated hook-up wire designed for internal wiring of electrical and electronic equipment. Manufactured in accordance with UL standards, it provides reliable electrical performance, good flexibility, and consistent quality for low voltage applications.
Product Name
UL 1007 c-UL Type TR-64
Type
UL 1007
Category Type
Electronic Cable
Range Size (AWG/mm²)
16 AWG ~ 32 AWG
Material
Conductor: Stranded or solid tin-coated annealed copper wires
Insulation: PVC (Polyvinyl Chloride)
Sheath: -
Temperature
Heat-resistance class 80℃
Standar Packing
Coil & Bobbin
Application
Internal wiring of appliances and Electronics Equipments (Lead wire of primary circuits).
Product Standard
JIS C3152 (Tin Coated Annealed Copper Wire)
JIS C3102 (Annealed Copper Wire)
UL 758 (Appliance Wiring Material)
UL 2556 (Wire and Cable Test Methods)
RoHS Compliance
Yes
Rating Voltage
300 VAC
Heat Resistance Class
80℃
Test
Product Description
UL1007 is a PVC insulated hook-up wire designed for internal wiring of electrical and electronic equipment. Manufactured in accordance with UL standards, it provides reliable electrical performance, good flexibility, and consistent quality for low voltage applications.
