AVSSBf - Thin Wall Low-Voltage Cables for Motorcycles

Product Name

Type

AVSSBf

Category Type

Automotive Cable

Range Size (AWG/mm²)

0.3 ~ 1.25 Sqmm

Material

Conductor: Annealed Copper Wires Insulation: PVC (Polyvinyl Chloride) Sheath: -

Temperature

Heat-resistance class 80℃

Standar Packing

Coil

Application

This PVC insulated single core cable is use for low voltage circuits in automobiles, vehicles, and motorcycles

Product Standard

JIS C3102 (Annealed Copper Wire) Dimension Customer request JASO D625-2 (Test Methode)

RoHS Compliance

Yes

Rating Voltage

30VAC and 60VDC

Heat Resistance Class

80℃

Test

Product Description

AVSSB is an automotive wire with thin-wall PVC insulation and enhanced flexibility, designed for low voltage applications. It is ideal for complex wire harness routing, providing space and weight efficiency while maintaining reliable electrical performance.

A : Low-voltage cables for automobile

V : Vinyl

SS : Super thin Type

B : for Motorcycles

f : in nominal sectional area are indicates flexible
