AVH & AVHf - Insulated heat resistant low-voltage cables for automobiles
Category : Cables
Product Description
AVH is a PVC insulated automotive wire designed for low voltage applications with improved heat resistance. It provides stable electrical performance, good flexibility, and durability, making it suitable for general automotive wiring, including areas exposed to elevated temperatures. (JIS C 3005)
Product Name
AVH & AVHf - Insulated heat resistant low-voltage cables for automobiles
Type
AVH & AVHf
Category Type
Automotive Cable
Range Size (AWG/mm²)
0.3 ~ 20 Sqmm
Material
Conductor: Annealed Copper Wires
Insulation: PVC (Polyvinyl Chloride)
Sheath: -
Temperature
Heat-resistance class -40℃ ~ 120℃
Standar Packing
Coil
Application
This PVC insulated single core cable is use for low voltage circuits in automobiles, vehicles, and motorcycles
Product Standard
JIS C3102 (Annealed Copper Wire)
JIS C 3406 (Dimension & characteristics)
JIS C 3005 (Test Methode)
RoHS Compliance
Yes
Rating Voltage
30 VAC and 60 VDC
Heat Resistance Class
105℃
Test
