AV & AVf - Low-Voltage Cables for Automobiles
Category : Cables
Product Description
AV is an automotive wire with PVC insulation, designed for low voltage applications. It provides reliable electrical performance and is suitable for general wiring in automotive systems.
A : Low-voltage cables for automobile
V : Vinyl
f : in nominal sectional area are indicates flexible
Product Name
AV & AVf - Low-Voltage Cables for Automobiles
Type
AV & AVf
Category Type
Automotive Cable
Range Size (AWG/mm²)
0.3 ~ 100 Sqmm
Material
Conductor: Annealed Copper Wires
Insulation: PVC (Polyvinyl Chloride)
Sheath: -
Temperature
Heat-resistance class 80℃
Standar Packing
Coil & Bobbin
Application
This PVC insulated single core cable is use for low voltage circuits in automobiles, vehicles, and motorcycles
Product Standard
JIS C3102 (Annealed Copper Wire)
JIS C 3406 (Dimension & characteristics)
JIS C 3005 (Test Methode)
RoHS Compliance
Yes
Rating Voltage
30 VAC and 60 VDC
Heat Resistance Class
80℃
